Raft Aquaculture Cage

Main Performance
Wind Resistance	Wave Resistance	Current Resistance
12	5m	1m/s

Product Technical Specifications
Item	Technical Requirements	Control Indicators	Tensile Yield Strength
Tensile Yield Strength/MPa	GB/T8804.3	≥20	≥21.5
Elongation at Break/%	GB/T8804.3	≥350	≥350
Longitudinal Shrinkage/%	GB/T6671	≤3.0	≤3.0
Oxidation Induction Time/min	GB/T19466.6	≥20	≥25
Flexural Strength/MPa	GB/T99341	≥10	≥15

Related Categories

New products

Product Details

Specifications and materials for square gabion floating frames
Floating frame specifications for gabion cages: Length x Width / m	Component Name	Material Specifications
		Material	Code Name	Average outer diameter of pipe / mm	Minimum wall thickness/mm
3X3	Floating tube	Fe80或PE100	SDR 17	250	14.8
4X4
5X5	Column		SDR 13.6	125	9.2
6X6
8X5	Handrail tube		SDR 11	110	10
8X8
10X10
12X12
Note: The length and width of the cage refer to the distance between the center lines of the inner floating tubes on the floating frame.

Our Raft Aquaculture Cage is the preferred solution for sheltered bay aquaculture and shallow nearshore fish farming projects across global coastal regions.

Built with a professional modular floating raft system, the entire cage structure is lightweight, layout-flexible, and easy to reposition or relocate to adapt to changing water depth and sea conditions. All floating components are manufactured from high-strength, corrosion-resistant marine-grade materials, perfectly matched with premium anti-fouling aquaculture netting. The combination ensures stable, long-lasting performance in calm coastal waters, inland lagoons and shallow sea environments.

Cost-efficiency and low maintenance make our raft fish cage an ideal choice for small to medium-scale aquaculture operators. It requires minimal daily upkeep while maintaining optimal water exchange and a healthy living environment for aquatic stock.

We provide fully customized raft layout configurations, size specifications and tailored structural designs. Our complete aquaculture raft EPC project support covers full lifecycle services from design, fabrication, on-site layout planning to installation and after-sales technical assistance, delivering reliable turnkey solutions for global clients.
