Square Offshore Aquaculture Cage

Main Performance
Wind Resistance Wave Resistance Current Resistance
12 5m 1m/s
Product Technical Specifications
Item Technical Requirements Control Indicators Tensile Yield Strength
Tensile Yield Strength/MPa GB/T8804.3 ≥20 ≥21.5
Elongation at Break/% GB/T8804.3 ≥350 ≥350
Longitudinal Shrinkage/% GB/T6671 ≤3.0 ≤3.0
Oxidation Induction Time/min GB/T19466.6 ≥20 ≥25
Flexural Strength/MPa GB/T99341 ≥10 ≥15

Product Details

Specifications and materials for square gabion floating frames
Floating frame specifications for gabion cages: Length x Width / m Component Name Material Specifications
Material Code Name Average outer diameter of pipe / mm Minimum wall thickness/mm
3X3 Floating tube Fe80或PE100 SDR 17 250 14.8
4X4
5X5 Column SDR 13.6 125 9.2
6X6
8X5 Handrail tube SDR 11 110 10
8X8
10X10
12X12
Note: The length and width of the cage refer to the distance between the center lines of the inner floating tubes on the floating frame.

Our Square Offshore Aquaculture Cage is a practical and efficient solution tailored for coastal inshore aquaculture and intensive fish farming. It is specifically engineered to address the core needs of large-scale, standardized breeding operations, combining structural stability with operational convenience.

Crafted from marine-grade HDPE material, the square fish cage boasts excellent corrosion resistance and structural rigidity, capable of withstanding moderate wind and wave impacts in nearshore and offshore environments. Its geometric square design optimizes space utilization, maximizing the use of breeding area while ensuring stable water circulation and smooth operation.

The square structure allows for neat and orderly grid layout, making it easy to manage daily feeding, net replacement, and equipment maintenance. We provide customized size specifications, along with professional EPC turnkey services—including custom design, equipment supply, on-site installation, and after-sales support—to perfectly match your farming scale and site conditions.

Equipped with high-performance anti-fouling netting and supporting accessories, the square fish cage effectively reduces maintenance workload and operational costs, while ensuring reliable performance and long-term stable operation. It is an ideal choice for intensive aquaculture, helping global clients achieve efficient, sustainable, and standardized farming operations.
